Cold Rolled Bright Surface 321 Stainless Steel Plate with High Temperature Resistance

Certification : RoHS, AISI, ASTM, GB, DIN, JIS

MOQ : 50

Price : 2.66

Shape : Flat

Technique : Cold Rolled

Surface Treatment : Bright

Specification : 1220*2440, 1500*3000, 1500*6000, 2000*6000mm

Thickness : 0.6 to 80 mm

Width : 1219mm, 1500mm, 1800mm, 2000mm

Length : 2m, 2.44m, 3m, 6m or as required

Finish : SATIN, 2B, 2D, BA NO (8), CR, HR, No.1, 1D, No.4, BA, 8K, hairline, brush, mirror

Carbon Content : 0.08 wt%

Chromium Content : 17.0-19.0 wt%

Nickel Content : 9.0-12.0 wt%

Yield Strength : 30 ksi min

Tensile Strength : 75 ksi min

Elongation : 40% min

Hardness : 95 Rb max

Contact Now

POSCO BAOSTEEL TISCO Stainless Steel Plate 321 SS Plate
Product Overview

Grade 321 stainless steel is a titanium-stabilized austenitic stainless steel designed for service in the 1000-1600°F temperature range. This material offers excellent resistance to intergranular corrosion and polythionic acid stress corrosion cracking.

Product Specifications
Product Type 321 Stainless Steel Sheet, 321 Stainless Steel Plate
Specification ASTM A240 / ASME SA240
Dimensions Cold rolled: 4ft*8ft [1219*2438mm]
Hot rolled: 5ft*20ft, 6ft*20ft [1500*6000mm, 1800*6000mm, 2000*6000mm]
Thickness 0.6 to 80 mm
Width 1219mm, 1500mm, 1800mm, 2000mm
Length 2m, 2.44m, 3m, 6m or as required
Finish Satin, 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), No.1 finish hot rolled, 1D, No.4, BA, 8K, hairline, brush, mirror, etc.
Available Forms & Services

Forms/Shapes: Plate, Sheet, Coils, Foils, Strip, Flats, Clad Plate, Plain Sheet, Rolling Sheet, Rolling Plate, Flat Shim, Flat Sheet, Shim Sheet, Rolls, Blank (Circle)

Processing Services: Laser Cutting, bending, welding, polishing

Chemical Composition
Element 321 Stainless Steel
Carbon 0.08
Chromium 17.0-19.0
Nickel 9.0-12.0
Manganese 2.00
Silicon 0.75
Nitrogen 0.10
Phosphorus 0.045
Sulfur 0.030
Titanium 5(C+N) min / 0.70 max
Mechanical Properties
Property 321 Stainless Steel
Yield Strength, min. (ksi) 30
Tensile Strength, min. (ksi) 75
Elongation, min. (%) 40
Hardness, max. (Rb) 95
Applications
  • Aircraft piston engine manifolds
  • Expansion joints
  • Firearms production
  • Thermal oxidizers
  • Refinery equipment
  • High temperature chemical process equipment
Alternative Grades Comparison
Grade Why it might be chosen instead of 321
304L Requirement for resistance to intergranular corrosion, not for high-temperature strength
3CR12 Only mild "high temperature" environment up to about 600°C
304H Only mild "high temperature" environment up to about 800°C
310 Operating environment temperature up to about 1100°C - too high for 321 or 321H
S30815 (253MA) Operating environment temperature up to about 1150°C - too high for 321 or 321H
Additional Available Grades

We also supply: 201, 202, 304, 304L, 304H, 309S, 310S, 310H, 310Si2, 316L, 316Ti, 316LN, 317L, 321, 347, 409L, 410, 410S, 416, 420, 430, 431, 436L, 439, 441, 443, 444, S31803, S32750, 904L, S30815, S31254, C276, C4, 600, 625, etc.
