| Product Details |
| Product name | Super Austenitic Stainless Steel Pipe 1.4501 / Al-6XN UNS N08367 |
| Brand name | TISCO BAO XIN STEEL |
| Standard | ASTM A312, ASTM A554, ASTM A790, EN10216-5, EN10217-7, JIS G3468, JIS G3459 |
| Material | N08367 Al-6XN 1.4501 Incoloy25-6hn NAS 255NM |
| Surface | Pickling, 400grit polishing, 600grit polishing, mirror finish |
| Certificate | BV, LR, GL, NK, RMRS |
| Packing | In bundles with waterproof material, in wooden cases |
| Shipment | By sea, by air, by express |
Incoloy 25- 6HN Super Austenitic Stainless Steel Plate 1.4501 / Al-6XN UNS N08367
ASTM A312, ASTM A213 ,Incoloy25-6hn N08367 Al-6XN 1.4501 NAS 255NM Super Austenitic Stainless Steel Plate
Material Description:
Incoloy25-6hn (UNS N08367) is a super austenitic stainless steel with excellent resistance to chloride ion pitting and crevice corrosion. As a corrosion-resistant alloy with good cost performance, its comprehensive corrosion resistance is relatively higher than that of 316L It is a great leap forward, and its corrosion resistance is close to other corrosion-resistant nickel-based alloys such as C-276, and the cost advantage is obvious. Because of the significant nitrogen content added to the alloy, the Al-6XN material has higher tensile strength than conventional austenitic stainless steels (such as 304, 316, 317, etc.), while maintaining excellent material toughness and impact strength. ASME Standard The allowable stress value specified in the specification, Incoloy25-6hn is 40% higher than 316L and nearly double that of copper-nickel alloy. Typical conditions: 60% sulfuric acid, below 80 ° C, annual corrosion rate <0.1mm Supporting welding materials and welding process: AWS A5.14 welding wire ERNiCrMo-3 or AWS A5.11 welding rod ENiCrMo-3 is recommended for alloy welding. Welcome to call for welding process and instructions.
Main chemical composition:
| (C) ≤ 0.02 | (Mn) ≤ 2.00 | (Ni) 23.5 ~ 25.5 | (Si) ≤ 1.0 |
| (P) ≤ 0.04 | (S) ≤ 0.01 | (Cr) ) 20.0 ~ 22.0 | (Cu) ≤0.75 |
| (Mo) 6.0 ~ 7.0 | (N) 0.18 ~ 0.25 | | |
Application areas:
Chemical vessels and pipelines, installation systems for offshore oil and gas platforms, condensers in contact with seawater or crude oil, heat exchangers and piping systems, filter presses for pulp bleaching, storage tanks and pressure rollers, thermal power plants, steel mills, Flue gas desulfurization equipment (FGD) for petrochemical companies, crude oil distillation towers and packings, desalination equipment and pumps, servo water piping systems for nuclear power plants, transformer enclosures exposed to the marine environment, pharmaceutical equipment (for the purity of medicines), food production device.
Size Range for tubing:
| OD:1/4" (6.25mm) to 8" (203mm) |
| WT 0.02" (0.5mm) to 0.5"(12mm) |
| Length:15m(Max) or as your requirement |
Process:
Cold drawn, Cold rolled, Precision Rolled for Seamless Pipe or Tube
Gas tungsten arc welding, Plasma arc welding (PAW),Submerged arc welding (SAW) For Welded Pipe or Tube
Finish: Annealed & pickled, bright annealing, polished
Ends: Beveled or plain end, square cut, burr free ,Plastic Cap at Both end
Packing: Bare packing/bundle packing with woven bag/wooden or steel frame crate packing/plastic cap protection at the both sides of tubes and suitably protected for sea-worthly delivery or as requested.
Inspection and Test Procedure
1. 100% PMI,Spectro Chemical Aanlysis Test for Raw Material
2. 100% Dimension & Visual Examination
3. Mechanical Properties Test Include Tension Test,Flaring Test (For Seamless tube/pipe)/ Flange Test (For Welded Pipe & Tube), Hardness Test ,Reversed Flattening Test
4. 100% Hydrostatic Test or 100% NON-DESTRUCTIVE Test (ET or UT)
5. Radiographic Test for Welded Pipe (shall be accordance with specification,or shall be as agreed upon between the purchaser and vendor)
6. Straightness Test (optional)
7. Roughness Test (optional)
8. Intergranular Corrosion Test(optional)
9. Impact Test (optional)
10. Grain Size Determinations (optional)
NOTES : ALL THE TESTS AND INSPECTION RESULT NEED TO BE SHOWED IN REPORTS ACCORDING TO STANDARD AND SPECIFICATION
